Liquid-Ring PumpHome > Products > Liquid-Ring Pump
Liquid-Ring Pump

The sanitary Liquid-Ring pump mainly used for transport the fluid which contains gas.  It is widely used in the working condition such as  liquid level not stable, even the liquid level lower than the pump inlet for sucking the liquid, it is also used as return pump in the CIP system

Specification:Flow Rate 10 m3/h-30m3/h

Operating Temperature:-20°C to +150°C(According to the seal material)

Body Material:316L(surface in contact with product)

                       304(surface in contact with product)

Mechanical seal:Sic/Carbon(Standard)

                        Sic/Sic (Optional)

Seal:   EPDM(Standard)

         Silicon, Viton, warp up PTFE (Optional)

Surface:Ra<0.4(surface in contact with product)

              Sub-photochromic or sand blasting(surface not in contact with product)

Mechanical seal option:single mechanical end seal, single mechanical end seal+oil seal water-cooled, double mechanical seal water-cooled.

Motor:

1.Mainly equipped ABB three phase current motor, meet the IEC60034,IEC60072 and CE standard.

2. Explosion motor can be selected.

3. Great electric property, Lower noise emission, lower shaking, IP55 for motor, F-class insulate.

4. Electric date:

  ≤3Kw,220-240V/380-420V,△/Y

  >3Kw,380-420V/660-690V, △/Y

      50Hz/60Hz

5. Working mode:continuous

6. Speed: 1450r/min(Grade 4)
