Specification：DN25~DN100,1.0"~4.0"

Operating Pressure：：-0.1Mpa ~+1.6Mpa

Operating Temperature：-20℃~+135℃ (According to seal material）

Body Material：304/316L(Touch fluid parts）

               304（Not touch fluid parts）

Valve Seat Material:  PTFE （Standard）

              PEEK、POM（Option）

Seal Material: EPDM(Standard）

              Silicon Rubber,  Fluorinated rubber, PEEK

Surface：Ra<0.8(Touch the fluid）

             Sub-photochromic or sand blasting（Not touch fluid)

Valve Body Structure: Straight Through, Three Way, Four Way

Connection Standard: DIN Series 2、3A、ISO1127 series1

Connection: Welding, Quick Joint, Flange and Thread

Valve Body Option: With emptying outlet, With cleaning and emptying outlet, valve seat covered

Control Mode: Manual, Normal ON, Normal OFF, Double Action

Spare Parts：Solenoid valve、Position feedback device etc...
